GE Multilin UR8AH
GE Multilin UR8AH is a current transformer (CT)/voltage transformer (VT) module, belonging to the GE Multilin UR series of general-purpose relay modules. It is mainly used to measure current and voltage signals in power systems and convert these signals into values recognizable by protective relays or other devices, usually used in conjunction with GE's power protection relays.
Functional Features:
- Comprehensive Protection: It can provide strong protection against various faults, including overcurrent, overvoltage, undercurrent, undervoltage, etc.
- Flexible Configuration: It can adapt to different protection schemes and application requirements, and can be flexibly configured according to actual situations.
- Advanced Communication: It can seamlessly communicate with external devices through multiple protocols such as Modbus RTU and DNP 3, facilitating system integration and data interaction.
- Compact Design: With a small size and adopting a rail-mounted installation method, it can be easily installed even in environments with limited space.
- Signal Processing: It provides isolated and scaled current and voltage signals for protective relays, improving personnel safety while enhancing the accuracy and reliability of the operating data of protective relays.
Technical Parameters:
- Current Input Channels: 3 1A/5A phase current transformers (CTs) and 1 1A/5A ground current transformer.
- Voltage Input Channels: 4 120V/240V voltage transformers (VTs).
- Accuracy: Class 0.5 for CTs and Class 1 for VTs.
- Load: Each CT and VT has a load of 5VA.
- Operating Temperature: -40℃ to +85℃.
Working Principle: UR8AH converts high-voltage and large-current signals in the power system into low-voltage and small-current signals through internal current transformers and voltage transformers. These signals are converted into digital signals after isolation and scaling processing. Then, the module sends the digital signals to protective relays or other devices through supported communication protocols, which are used for power system protection, monitoring, fault analysis, etc., to realize the monitoring and control of the operating status of the power system.
Application Fields:
- Power Systems: Widely used in power plants, substations, distribution networks and other places, for the protection of transmission lines, generators and transformers, monitoring the operating status of power systems, and providing protection functions such as overload and short circuit.
- Industrial Fields: In industries such as petroleum, natural gas, chemical industry, and manufacturing, it can be used to monitor and protect the operation of industrial equipment, control motors, valves and other equipment, and realize automated production.
- Construction Fields: Suitable for data centers, commercial buildings, etc., it can participate in power quality monitoring and real-time monitoring of parameters such as voltage, current, and power factor.
