Description

ABB PFTL101A-2.0kN 3BSE004172R1

ABB PFTL101A-2.0kN (Order No.: 3BSE004172R1) is a medium-range high-precision tension/load cell under ABB's Pressductor® magnetoelastic technology platform, belonging to the Pillow Block load cell series. Specifically designed for the accurate measurement of tension, pressure and weight within the 2.0kN range in industrial scenarios, it is the core basic model of ABB's medium-load tension measurement product line. Relying on the unique advantages of magnetoelastic technology, this sensor can operate stably in various harsh industrial environments and is widely used in medium-load tension control and precision weighing scenarios.

1. Working Principle and Structural Features

This sensor achieves precise force measurement based on the magnetoelastic effect (also known as piezomagnetic effect): when mechanical force acts on the measuring assembly, the magnetic permeability of the internal material changes regularly. A dedicated detection circuit converts this change in magnetic permeability into a stable and accurate electrical signal, and finally completes the force measurement. Compared with traditional strain gauge sensors, its non-contact and wear-free measurement method fundamentally solves the problems of strain gauges being prone to fatigue and short service life, and also has stronger anti-interference ability and long-term operation stability.

Structurally, it adopts a practical and compact design, mainly composed of a measuring assembly (FR), a force conversion assembly (FV) and a 316L stainless steel housing. The housing is hermetically sealed by laser welding, with an IP67 protection rating, which can effectively resist the impact of harsh environmental factors such as dust, humidity, corrosive gas and strong vibration, and is suitable for various severe industrial scenarios. As a horizontal-measurement pillow block sensor, it supports both horizontal and inclined installation methods, which is easy to install and highly adaptable, and can be flexibly integrated into various industrial equipment and production lines.

2. Core Technical Specifications

All technical specifications of the sensor have been strictly factory-calibrated, with excellent precision and stability. The core parameters are as follows (taking into account authoritative calibration values to ensure accuracy and referability):

Rated Load: 2.0kN (i.e., 2000N, approximately 450lbs, equivalent to 204 kilogram-force);
Measurement Accuracy: ±0.2% full scale (F.S.), up to ±0.25% FSO in 220V AC power supply scenarios, comprehensive error ≤0.03% F.S. (compliant with Class C3 accuracy standard);
Nonlinearity: ±0.05% F.S., Hysteresis: ±0.03% F.S., Repeatability: ±0.02% F.S.;
Creep Performance: Creep ≤±0.02% F.S. within 30 minutes, annual drift rate ≤±0.02% F.S., with outstanding long-term stability;
Output Signal: Standard 2.0mV/V analog signal (based on excitation voltage); optional 4-20mA DC signal (matching signal converter required);
Excitation Parameters: 10V DC~15V DC (12V DC recommended), 12-24V DC wide voltage supported in some scenarios; maximum excitation current 60mA, low-power design;
Response Performance: Response time ≤5ms, real-time data processing up to 125μs, capable of capturing minimum 0.4N micro-force fluctuation;
Overload Capacity: Maximum overload 10.0kN in measurement direction, allowable transverse load 30.0kN, effectively avoiding damage caused by accidental overload;
Physical Characteristics: Deflection 0.012mm, spring constant 140kN/mm, high structural rigidity, no obvious deformation during measurement;
Operating Environment: -20℃~+80℃ (partially calibrated -20℃~+70℃, subject to actual working conditions), IP67 protection;
Electrical Protection: Built-in radio frequency interference filter, with multiple protections of overload, short circuit and open circuit, strong anti-electromagnetic interference ability;
Others: Supports single-point grounding, parallel power supply and redundancy technology; factory pre-calibrated, ready to use after unboxing, no on-site calibration required.

3. Core Product Advantages

High Precision and Stability: Magnetoelastic core technology + strict factory calibration, high precision, small drift, service life up to 15 years, reducing equipment replacement frequency by 60%;
Harsh Environment Adaptability: 316L stainless steel sealed housing + IP67 protection, capable of stable operation in humid, dusty, highly corrosive and strong vibration scenarios;
Outstanding Anti-Interference: Built-in radio frequency interference filter, high-power low-impedance AC output, strong resistance to electrical interference and ground fault;
Easy Installation and Integration: Supports horizontal/inclined installation, requires matching PFTL101A dedicated adapter plate (minimum thickness 32mm), no complex debugging;
High Compatibility: Seamlessly connects with ABB PFEA series tension controllers, compatible with various PLC and DCS systems, and supports parallel use and redundant configuration.

4. Application Scenarios

As a medium-range high-precision measurement device, it is suitable for tension detection of medium-load strips, wires, films and other materials, as well as pressure monitoring and precision weighing of industrial equipment, widely used in:

Metal Processing: Tension control of metal wire and conventional strip processing lines, ensuring processing accuracy and reducing defective rate;
Paper Making, Printing and Packaging: Transverse tension control of paper and film in conventional paper machines, film slitting machines and coaters;
Other Fields: Tension control of textile yarns, weighing of automated production lines, pressure monitoring of material handling, as well as precision weighing and tension control in food, pharmaceutical and chemical production (suitable for scenarios with medium rolls, moderate tension range and high precision requirements).
