MOOG D136-002-005 with D138-002-002

I. Combo Kit Positioning and Multi‑Scenario Adaptability

1. Exclusive MSCI Controller + Motion Authorization ComboSpecially designed for the M3000 platform, D136-002-005 acts as the core hardware, integrating Profibus slave and EtherCAT master functions to provide robust bus communication and multi-axis control hardware support. D138-002-002, as a Motion-level license, unlocks the complete motion control function package of the controller. Together they realize advanced motion control functions such as multi-axis interpolation, electronic gear, cam synchronization, and high-speed positioning. Primarily used in hydraulic / electric actuator systems, they meet high-end motion control requirements including ESD valve control, wind turbine pitch control, metallurgical mill screw-down, and precision mold clamping in injection molding machines, fully leveraging MOOG’s 50 years of technological expertise in electric and hydraulic motion control.


2. Adaptation for Industrial Automation System Integration and UpgradesCompatible with the full range of Moog M3000 expansion modules (analog / digital I/O, bus modules), enabling seamless integration into existing DCS/PLC automation systems (e.g., ABB AC800M, Siemens S7-400FH). For legacy motion control systems, it can directly replace original controllers and authorization components without major cabinet, wiring or program modifications; advanced functions can be activated with simple configuration, greatly reducing production line upgrade costs. Suitable for installation in control cabinets in Class I Div 2 hazardous areas, resistant to strong electromagnetic interference and wide temperature ranges, and capable of operating under complex industrial conditions.


3. Adaptation for Complex Bus and Hybrid Drive ScenariosRelying on the Profibus slave and EtherCAT master capabilities of D136-002-005, it enables high-speed coordinated communication among multiple controllers and actuators, meeting distributed control demands of large-scale production lines. Paired with the hybrid drive control functions unlocked by D138-002-002, it supports mixed feedback from analog, digital, SSI / incremental encoders, and can control hydraulic valve manifolds and servo motors simultaneously within the same system. It adapts to complex multi-media drive scenarios such as ship steering gears, offshore platform jacking systems, and thermal power governor control, while supporting flexible switching of multiple communication protocols.

II. Core Functions and Technical Advantages of the Combo Kit

(I) Core Collaborative Functions

• Full Activation of Advanced Motion Control FunctionsThe D138-002-002 license unlocks the PLCopen standard motion control library and Moog proprietary motion function blocks for the D136-002-005 controller, enabling multi-axis synchronization, linear / circular interpolation, electronic gear, electronic cam, and three-loop closed-loop control of speed / position / torque. It supports PWM precision driving of hydraulic servo valves and vector control of electric servo motors, meeting fast control cycle requirements down to 500μs. It also allows access to the rich function module library in MASS software (e.g., filters, nonlinear functions, function generators), simplifying the implementation of complex control projects.
•

• Collaborative High-Speed Bus CommunicationD136-002-005 features a built-in Profibus slave and EtherCAT master. Combined with the CANopen and Ethernet TCP/IP communication libraries unlocked by D138-002-002, it enables high-speed data exchange among multiple devices, supporting seamless connection with upper-level SCADA systems, other controllers, and field actuators. It provides remote monitoring, parameter downloading, data traceability and fault diagnosis. Supporting OPC/DDE interfaces, it facilitates integration into factory intelligent management systems, and features graphical bus configuration to simplify communication parameter setup.
•

• Plug-and-Play and Rapid DeploymentThe D136-002-005 controller is mounted on a 35mm DIN rail, with a modular design for easy cabinet layout and expansion. The green D138-002-002 dongle plugs directly into the dedicated license slot of the controller; the license is automatically recognized upon power-up with no additional programming required. Paired with the integrated programming, debugging and visualization functions of MASS software, it enables fast project deployment and commissioning, reducing programming workload.
•

• Function Compatibility and Expansion & UpgradeThe combo kit is fully compatible with all functions of the basic Controls license (PLC logic, I/O control, basic communication). If more advanced control functions are required later, the Professional-level license (D138-002-003) can be directly added without repurchasing hardware or basic authorization. D136-002-005 supports seamless cooperation with Moog M3000 series expansion modules, allowing flexible expansion of system I/O capacity and functions. It also supports Web-based visualization for convenient remote operation and monitoring.
•


(II) Technical Advantages

• Collaborative Reliability of Hardware + LicenseThe D136-002-005 controller features an industrial-grade sealed design with IP20 protection, resistant to vibration and shock (compliant with IEC 60068-2-6/27), equipped with comprehensive fault diagnosis (capable of detecting wiring faults, power supply faults, etc.) and watchdog protection. The D138-002-002 license key has no internal battery or wearable components; license data is stored in non-volatile Flash memory, resistant to power loss and electromagnetic erasure to prevent authorization loss. Both support online hot-swapping during non-interlocking periods to ensure continuous system operation. The controller also features analog signal processing and multiple protection functions to enhance system stability.
•

• Wide Environmental AdaptabilityThe two products in the combo kit have fully matched environmental specifications: operating temperature -40℃ ~ 70℃, relative humidity 5%–95% (non-condensing), storage temperature -40℃ ~ 85℃. They ensure long-term stable operation in control cabinets in extreme environments such as deserts, offshore platforms and cold-region power plants. The controller’s analog interfaces feature ±36V overvoltage protection, digital outputs feature short-circuit protection, and EMC immunity complies with EN 61000-6-2/4 industrial standards, adapting to harsh industrial electromagnetic environments.
•

• Low Maintenance and High CompatibilityNo separate calibration is required for the controller or license; license status can be directly read via MASS software, and controller faults can be quickly located through the software. Compliant with IEC 61131-3 programming standards, with motion function blocks conforming to PLCopen specifications, facilitating cross-platform program porting by engineers. D136-002-005 supports multiple communication protocols and is compatible with industrial equipment of different brands, adapting to various industrial automation scenarios. MASS software integrates programming, testing, debugging, documentation and visualization functions, further reducing maintenance and operation difficulty.
•

• High Precision and High EfficiencyThe D136-002-005 controller features high-precision signal processing capabilities. Paired with the advanced motion algorithms unlocked by D138-002-002, it achieves micron-level positioning accuracy and fast response within 100ms, meeting the extremely high requirements for control accuracy and response speed in precision manufacturing, wind turbine pitch control and other scenarios. The collaborative design of the EtherCAT master and Profibus slave greatly improves bus communication speed, handles dynamic disturbances in complex motion control, and optimizes motion control performance to ensure equipment operating efficiency and control accuracy.

III. Application Scenarios of the Combo Kit

1. Energy and Electric Power IndustryServo control of steam turbine governors and gas turbine fuel valves in thermal power plants, multi-axis synchronous control of wind turbine pitch systems, precision positioning of turbine wicket gates in hydropower plants. The combo kit enables fast response (<100ms) and overshoot-free control of governors, improving unit operating efficiency and stability. High-speed bus communication realizes real-time monitoring and data traceability of unit status, ensuring reliable operation of the power system.


2. Metallurgy and Heavy Manufacturing IndustryScrew-down gap control in rolling mills, tension synchronization in coilers, mold oscillation control in continuous casters. In hydraulic AGC (Automatic Gauge Control) systems, multi-axis synchronization achieves micron-level adjustment of steel plate thickness. High-speed data exchange supported by the license handles dynamic disturbances during the rolling process. The high reliability of the controller adapts to the high-vibration, high-dust conditions of the metallurgical industry, while precise flow control improves production quality.


3. Shipbuilding and Offshore Engineering IndustryHydraulic servo control of ship steering gears, synchronous driving of offshore platform jacking legs, positioning systems for offshore wind installation vessels. The combo kit hardware operates reliably in high-vibration, salt-spray corrosive environments. Motion algorithms and bus communication capabilities ensure surge resistance and high-precision positioning of equipment, meeting the harsh operating requirements of offshore engineering. It also supports multi-device coordinated control to improve operational safety and efficiency.


4. Precision Manufacturing and Injection Molding IndustryServo control of mold clamping / injection in large injection molding machines, closed-loop injection speed control in die-casting machines, multi-axis interpolation control in semiconductor wafer handling robots. It achieves pressure / speed dual closed-loop control during the molding process to improve product yield. The high precision of the controller and advanced motion functions unlocked by the license meet the extremely high requirements for control accuracy and stability in the precision manufacturing industry. Visualization functions in MASS software facilitate equipment status monitoring and parameter adjustment.

IV. Technical Parameters of the Combo Kit
