ABB UFC718AE101 HIEE300936R0101
1. Product Description
ABB UFC718AE101 HIEE300936R0101 is an industrial automation control module specially designed for process control, data acquisition and equipment coordination in complex industrial scenarios. It undertakes key tasks such as real-time control logic execution, multi-protocol data communication, sensor signal processing, equipment status monitoring and fault protection. The module strictly complies with IEC 61131-3 and IEC 61850 industrial standards, adopts a modular redundant design and highly integrated circuit architecture, and is fully compatible with ABB AC 800M DCS, PLC systems and third-party industrial control equipment. It features strong electromagnetic interference immunity and harsh environment adaptability, and can be directly integrated into industrial automation control systems to meet the stringent requirements of control accuracy, reliability and scalability in power, chemical, manufacturing and other industries.
This module uses high-quality industrial-grade components and precision manufacturing technology, integrates a 32-bit industrial-grade ARM processor with high-capacity memory and storage, and supports wide-range voltage input and high protection grade. It has a compact structure and easy installation, supports flexible expansion of analog and digital I/O, and can realize seamless connection with host computers, sensors and actuators via various industrial communication protocols. With high stability, high scalability and convenient maintenance, it has become a core control component in industrial automation production lines, power system automation, petrochemical process control and other applications.
2. Technical Specifications
| Parameter Category | Details |
|---|---|
| Model / Order No. | Model: UFC718AE101 HIEE300936R0101; Type: UFC700 series industrial automation control module, belonging to ABB industrial control module series |
| Manufacturer | ABB (Country of origin: Switzerland/Europe; adopts high-quality industrial-grade components and highly integrated circuit design, full-process strict quality inspection, complies with international standards including CE, UL, CSA, IEC 61131-3, IEC 61850, EN 55032 to ensure long-term stable operation) |
| Product Type | Industrial automation control module for process control, real-time data acquisition, multi-protocol data communication, sensor signal processing, equipment status monitoring and fault protection in complex industrial scenarios, suitable for various industrial automation control systems |
| Core Functions | 1) Control: Supports multi-loop control, sequence control and batch control, and can execute complex control algorithms and logic operations.2) Data Acquisition: Collects 8-channel analog and 16-channel digital signals in real time to accurately capture equipment operating parameters and status changes.3) Signal Output: Provides 4-channel analog and 8-channel digital outputs to drive various industrial actuators.4) Communication: Supports multi-protocol data transmission for seamless connection with host computers, PLCs, sensors and actuators.5) Fault Protection & Diagnosis: Integrates overcurrent, overvoltage and overtemperature protection; features module self-diagnosis, communication fault diagnosis and signal over-range alarm.6) Expansion: Modular architecture supports flexible I/O expansion to adapt to industrial control systems of different scales. |
| Electrical Parameters | Operating voltage: Wide-range 24VDC/48VDC, supports 18–80VDC;Operating current: Typical 180mA (24VDC), max. 250mA (24VDC);Power consumption: Typical 4.3W, max. 6.0W;Output current: Max. 2A per channel;Analog input: 8 channels (configurable 4–20mA/0–10V);Digital input: 16 channels (dry/wet contact);Analog output: 4 channels (0–10V DC);Digital output: 8 channels (relay contact). |
| Communication & Interface | Standard: 1× Gigabit Ethernet (TCP/IP, 10/100/1000Mbps auto-negotiation), 2× RS485 (Modbus RTU/TCP, 9.6kbps–115.2kbps configurable), 1× CAN bus, 1× Profibus DP;Multi-protocol compatible, seamless connection with ABB AC 800M DCS, PLC, SCADA and third-party equipment for high-speed and stable data exchange. |
| Physical Characteristics | Mounting: 35mm DIN rail / panel screw mounting;Ingress protection: IP67 (dustproof, waterproof, oil-proof, for harsh industrial sites);Dimensions: 130mm × 70mm × 32mm (L×W×H);Net weight: approx. 0.3kg;Processor: Industrial 32-bit ARM, 500MHz;Memory: 256MB DDR3 RAM, 512MB Flash. |
| Environmental | Operating temperature: -40℃ ~ +85℃;Storage temperature: -55℃ ~ +90℃;Relative humidity: 5% ~ 95% (non-condensing);Vibration / shock: Complies with industrial standards;EMC: Complies with EN 55032 / EN 61000-6-2 / EN 61000-6-4, strong anti-interference. |
| Reliability | MTBF ≥ 500,000 hours;Modular redundant design for stable operation;Triple protection: overcurrent, overvoltage, overtemperature;Industrial sealed housing, dustproof, waterproof, oil-proof;Complete self-diagnosis and alarm for fast troubleshooting. |
3. Functions & Features
(1) Powerful Computing & Precise Control
- High-performance processor: Equipped with 32-bit industrial ARM processor at 500MHz, providing strong computing capability to efficiently execute complex control algorithms and real-time logic without delay.
- Full signal compatibility: Supports 8 configurable analog inputs, 16 digital inputs, 4 analog outputs, 8 digital outputs, matching various sensors and actuators.
- Multi-mode control: Supports multi-loop, sequence and batch control, configurable flexibly according to production processes for both simple and complex applications.
(2) Flexible Communication & Easy Expansion
- Multi-protocol native support: Directly supports Modbus RTU/TCP, Profibus DP, Ethernet, etc., enabling seamless integration with ABB and third-party systems without extra gateways.
- Abundant interfaces: Gigabit Ethernet, RS485, CAN bus and Profibus DP build redundant communication links for high reliability.
- Modular expansion: Analog and digital I/O modules can be added or removed freely, reducing upgrade and retrofit costs without replacing the main unit.
(3) Harsh Environment Adaptation & Safety Protection
- IP67 high protection: Sealed housing is dustproof, waterproof and oil-proof, suitable for outdoor, humid and dusty sites without extra protection.
- Wide temperature & voltage: 18–80VDC input and -40℃~+85℃ operating range adapt to extreme temperatures and unstable power supply.
- Triple safety protection: Overcurrent, overvoltage and overtemperature protection prevent module damage; signal over-range alarm ensures system safety.
(4) High Reliability & Convenient Maintenance
- Ultra-high stability: MTBF ≥ 500,000 hours with industrial-grade components and strict quality control, minimizing downtime.
- Full self-diagnosis: Monitors running status, communication links and signal integrity with accurate fault feedback for quick repair.
- Easy installation & O&M: DIN rail or panel mounting, compact size, remote monitoring and configuration via host system to reduce workload.
4. Applications
- Industrial automation: Integrated into automated production lines and smart factories for precise control, data acquisition and status monitoring in manufacturing and electronics industries.
- Power systems: Used in thermal, wind, photovoltaic, energy storage and distribution network systems for equipment monitoring, signal acquisition and control.
- Petrochemical industry: Applied in process control and plant monitoring under high-temperature, corrosive and strong-interference environments for reactors, valves and pumps.
- Other industries: Water treatment, metallurgy, mining automation, rail transit power supply, large compressors, industrial boilers, and legacy control system upgrades.
5. FAQs & Troubleshooting
Module fails to start, power LED off
Check if input voltage is within 18–80VDC; correct low voltage, reversed polarity or loose wiring.Inspect the power interface for damage; replace the cable and test again.If power is normal but still inactive, contact ABB authorized service for repair or replacement.
Abnormal signal acquisition inconsistent with actual value
Verify input signal type (4–20mA/0–10V) matches module configuration.Check sensor wiring and polarity; troubleshoot sensor faults.Calibrate accuracy and adjust parameters via host software.Reduce on-site electromagnetic interference with shielding if needed.
Communication lost, cannot connect to host or other devices
Check tightness of communication wiring; fix open or short circuits.Verify protocol (Modbus RTU/TCP, Profibus DP), IP address and baud rate match the host system.Test communication interface with diagnostic tools.Check firewall and switch port blocking; open required ports.Restart module and host system to resolve software communication errors.
Abnormal module output, actuator not responding
Check output wiring for loose connection or open circuit.Verify output signal type matches the actuator; test the actuator itself.Check output configuration in host software; restart module to refresh output.If internal output circuit is faulty, contact service for repair.
Frequent alarms and protection triggering
Check input voltage stability; resolve overvoltage or undervoltage.Ensure ambient temperature and humidity are within rated range to avoid overtemperature protection.Check output loop for short circuit or overload causing overcurrent protection.Verify signal range settings to prevent false over-range alarms.If all conditions are normal, send module for hardware inspection.
