Brand： ABB

Product ID： LDGRB-01 3BSE013177R1

Condition： New / used

Terms of payment： Paypal、T/T 、Western Union

Category:

Description

ABB LDGRB-01 3BSE013177R1

ABB LDGRB‑01 3BSE013177R1 is a digital input (DI) module that serves as a core component for field signal acquisition in industrial automation control systems. It belongs to the ABB S800 I/O series and is compatible with the System 800xA and AC 800M high‑performance control systems. Integrating five core capabilities—high‑precision digital signal acquisition, strong anti‑interference performance, comprehensive diagnostics, hot‑swap capability, and high compatibility—it is an important part of ABB’s industrial automation solutions.This module safely, reliably, and accurately converts various dry contact or passive contact signals from the field into digital signals recognizable by the controller. It is widely used in energy and power, industrial machinery, water treatment and environmental protection, marine engineering, automotive manufacturing, chemical engineering, and other fields. Suitable for various industrial automation systems, programmable logic controllers (PLC), and distributed control systems (DCS), it acts as a forward data acquisition outpost connecting field devices and control logic, providing reliable data support for industrial process control, equipment condition monitoring, and operation and maintenance management.


The module is mainly used for high‑precision acquisition of digital signals in industrial field applications. Its core function is to receive dry contact or Namur proximity switch signals from field devices such as pushbuttons, limit switches, relay contacts, and proximity sensors, convert them into digital signals identifiable by the system, and upload them in real time to main controllers such as the AC 800M via the backplane bus, providing accurate field status data for control logic execution.It features channel‑group isolation, which effectively suppresses crosstalk between channels and field common‑mode interference, ensuring accurate signal acquisition in complex electromagnetic environments. It is also equipped with comprehensive diagnostic functions, including module internal status diagnosis, field power supply monitoring, and wire break detection (with external resistors), enabling early detection of potential faults and predictive maintenance.The module is deeply integrated into the ABB industrial automation ecosystem, supporting seamless integration with S800 I/O stations, System 800xA, and AC 800M control systems. It works with communication interface modules such as CI853 and CI854, complies with relevant industrial automation standards, and provides excellent vibration and electromagnetic interference resistance, ensuring compliance and long‑term reliable operation in various complex industrial environments.


It adopts a compact industrial modular design for easy installation and user‑friendly maintenance. The plug‑in structure allows quick mounting on S800 I/O base units (such as the SD822 power/communication base and SA801 extension base), facilitating later removal and replacement. Clear LED status indicators enable rapid identification of power, operation, fault, and communication statuses for convenient on‑site troubleshooting.The housing uses industrial‑grade protective materials with excellent resistance to electromagnetic interference, dust, moisture, and vibration, suitable for harsh industrial environments such as compressor rooms, ship engine rooms, and painting workshops, supporting long‑term stable operation.It also supports hot‑swap operation, allowing replacement of faulty modules while the system is running without interrupting other channels, ensuring uninterrupted operation of critical loops and meeting the strict requirements of continuous process industries.




1. Technical Specifications


  • Power SpecificationsPower supply: industrial standard 24 VDC, suitable for field power conditions.Typical input current per channel: 6 mA at 24 VDC. Low power consumption for long‑term continuous operation.Comprehensive power protection prevents damage from abnormal supply or overload, improving operational safety.

  • Processing and Logic ParametersHigh‑speed signal processing with excellent response time: typical ON→OFF and OFF→ON response time is 3 ms, meeting fast process requirements and high‑frequency signal acquisition.Supports channel‑group isolation (typically 8 channels per group), effectively suppressing crosstalk and common‑mode interference for independent and accurate acquisition.Full diagnostic functions detect internal faults (e.g., watchdog error, memory fault) and report to the controller in real time via the backplane bus. Supports configurable field power monitoring and wire break detection (with external resistors).

  • Signal Processing SpecificationsDedicated digital input module for accurate field digital signal acquisition.Supports dry contact or Namur proximity switch inputs (depending on configuration) for 24 VDC level detection.16 digital input channels in a high‑density design, greatly saving cabinet space.Wide logic level thresholds:
    • Logic “1”: 15–30 VDC
    • Logic “0”: 0–5 VDCStrong anti‑interference performance avoids false signals and logic errors.Professional isolation and filtering further improve reliability and eliminate distortion caused by field interference.


  • Communication and Compatibility SpecificationsConnects to the main controller and communication modules via the S800 I/O backplane bus.Works with CI853, CI854, and other interface modules, supporting Profibus DP and other mainstream industrial protocols for real‑time data upload and precise command execution.Seamlessly integrates with ABB System 800xA, AC 800M, and the S800 I/O ecosystem. Suitable for retrofitting Bailey INFI 90 or Symphony systems to implement hybrid control.Supports TBs800 series high‑density front connectors for fast, reliable wiring.No complex software configuration required; physical installation completes electrical connection, greatly shortening commissioning time.

  • Environmental SpecificationsOperating temperature: 0 °C to +60 °C.Storage temperature: −40 °C to +70 °C, suitable for long‑term spare parts storage.Protection meets strict industrial standards with excellent dust and moisture resistance.Outstanding EMC and vibration performance; the locking mechanism passes IEC 60068‑2‑6 sinusoidal vibration testing. Stable in harsh environments with high inverter noise and mechanical vibration (e.g., ships, rolling mills).Natural convection cooling with no moving parts enables maintenance‑free operation and long service life.



2. Features


  1. High‑density digital input for versatile applications16 digital input channels in a compact design save significant cabinet space—up to 40% compared to conventional layouts. Supports both dry contacts and Namur proximity switches with 24 VDC detection. Widely compatible with field pushbuttons, limit switches, relay contacts, and sensors to meet various industrial signal acquisition needs.

  2. Strong anti‑interference design for accurate and reliable acquisitionChannel‑group electrical isolation (opto‑ or magnetic coupling) blocks common‑mode interference and crosstalk caused by ground potential differences. Wide threshold levels and dedicated filtering avoid false triggering. Each channel is sampled independently and accurately even in severe electromagnetic environments, providing a solid foundation for safe control logic.

  3. Comprehensive diagnostics enabling predictive maintenanceBeyond basic signal input, the module provides internal diagnostics, field power monitoring, and wire break detection. Faults are detected early and reported to the controller, supporting predictive maintenance instead of reactive repair. This greatly improves system availability and reduces unplanned downtime.

  4. Hot‑swap design for convenient and efficient maintenanceSupports online replacement under permitted system configuration and safety procedures. Faulty modules can be replaced without disrupting other modules in the same I/O station, ensuring continuous operation of critical loops and meeting strict availability requirements in continuous process industries. Plug‑in construction and clear LEDs speed up installation, removal, and troubleshooting.

  5. Seamless integration, high compatibility, and flexible deploymentPart of the ABB S800 I/O family, fully compatible with System 800xA and AC 800M, and supports legacy system modernization for hybrid control.“Plug and play” with minimal software configuration; physical installation completes electrical connection, shortening commissioning cycles.Can be installed locally in motor control centers (MCC) or field junction boxes for nearby signal acquisition, reducing long‑distance wiring costs and failure points and supporting edge I/O architecture.



3. Applications and Case Examples


  • Energy & Power IndustryUsed in auxiliary monitoring of small hydropower stations, environmental monitoring in PV inverter rooms, diesel generator control panels, and substations. Acquires equipment run/fault status, valve limits, and pushbutton signals for real‑time monitoring and control, ensuring stable power system operation. Also applied in substation temperature monitoring and protection systems for signal conditioning and acquisition.

  • Industrial Machinery & Automotive ManufacturingDeployed in local sensor/actuator interfaces for packaging lines, injection molding machines, and compressor stations to acquire run status and limit signals for coordinated control. In painting workshops of large automotive plants, it collects safety interlock and position signals from painting robots and elevators. Its high anti‑interference and stability greatly reduce unplanned downtime and improve production continuity.

  • Water Treatment & Environmental ProtectionInstalled in control cabinets of lift pump stations and filter backwash stations in municipal wastewater treatment plants. Directly connects to level switches, motor run signals, and valve open/close limits for automatic pump and valve control and status monitoring, supporting unattended operation. Also collects level, flow, and motor data for O&M optimization.

  • Marine & Offshore Engineering & Legacy System RetrofitsUsed in local control and feedback systems for marine engine room auxiliaries (lube oil pumps, cooling fans), operating reliably in high‑vibration, high‑humidity offshore environments. In legacy system upgrades, it serves as an extension module for Bailey INFI 90 or Symphony systems, adding AC 800M local I/O to implement hybrid control and enhance system performance.



4. Product Advantages


  • High‑density design saves space: 16 digital input channels in a compact form factor reduce cabinet space and deployment costs.
  • Strong anti‑interference & accurate acquisition: Channel‑group isolation and wide thresholds ensure stable, error‑free signal reading in harsh industrial environments.
  • Comprehensive diagnostics for efficient O&M: Internal monitoring, power supervision, and wire break detection enable predictive maintenance. Hot‑swap capability minimizes downtime.
  • Plug and play, flexible deployment: Simple installation, no complex configuration, suitable for local field mounting to reduce wiring and faults.
  • Ecosystem integration & wide adaptability: Seamless compatibility with System 800xA, AC 800M, and S800 I/O. Supports legacy retrofits and delivers stable, long‑term performance across multiple industries.
