ABB PP826A 5.7-inch button-operated industrial human-machine interface
ABB PP826A 5.7-inch button-operated industrial human-machine interface

ABB PP826A 5.7-inch button-operated industrial human-machine interface

ABB PP826A 5.7-inch button-operated industrial human-machine interface

Brand： ABB

Product ID： PP826A

Condition： New / used

Terms of payment： Paypal、T/T 、Western Union

Category:

Description

I. Basic Information


Model: PP826A

Part No.: 3BSE042244R2 / 3BSE042244R3

Brand: ABB

Series: Panel 800 Industrial Operator Panel Series

Product Type: 5.7-inch Keypad Industrial HMI Operator PanelCompatible Systems: ABB AC800M, 800xA, Freelance DCS Distributed Control Systems, widely applied in power, petrochemical, metallurgy process control and generator excitation & turbine control systems.


Product Positioning

This panel serves as the local human-machine interaction core unit for industrial process control systems. It realizes real-time two-way data communication with ABB controllers via Ethernet and RS485 buses, supporting on-site process monitoring, parameter configuration, equipment manual operation, fault alarm query and historical trend analysis. Equipped with physical industrial keypad and IP65 front protection, it avoids misoperation and touch failure caused by dust, moisture and oil pollution in harsh industrial sites, widely used in local operation station spare replacement, old cabinet HMI renovation and on-site production line operation & maintenance projects.


Hardware Architecture

  1. 5.7-inch TFT Color LCD Display Unit: Industrial LED backlight screen with 262,144 true colors, supporting dynamic process graphics, real-time trend charts and alarm pop-up windows, with 50000-hour long service life for 24/7 continuous on-site monitoring.
  2. Integrated Physical Keypad Operation Unit: Custom shortcut keys, numeric keys and directional navigation keys adopt dust-proof wear-resistant membrane design, binding equipment start-stop, screen switching, parameter modification and alarm reset functions to ensure stable and reliable frequent on-site operation.
  3. Isolated Multi-channel Communication Processing Unit: Equipped with RJ45 Ethernet and isolated RS485 interfaces, supporting mainstream industrial protocols to realize high-speed bidirectional data interaction between local panel and upper control system.
  4. Large-capacity Local Data Storage Unit: Non-volatile flash memory supports cyclic storage of over 1000 alarm and operation records, realizing off-line fault traceability without relying on upper monitoring software.
  5. Wide-range Power Supply & Multi-level EMC Protection Unit: Built-in reverse polarity, overvoltage, ESD and short-circuit protection; full conformal coated PCB and sealed front panel adapt to high-temperature, dusty and strong electromagnetic interference industrial environments.
  6. Standard Embedded Cabinet Mount Structure: Aluminum alloy front panel with passive heat dissipation design, no fan required, reducing on-site failure points and adapting to dense cabinet layout.


Mounting Specifications

  • Operating Power Supply: DC24V (18~30VDC wide range), total power consumption ≤12W
  • Display: 5.7-inch TFT LED, 640×480 resolution, 350cd/㎡ brightness, 50000-hour backlight lifespan
  • Operation: Custom function keys, numeric keys, directional navigation & confirm keys
  • Communication Interfaces: 1×RJ45 Ethernet, 1×isolated RS485
  • Supported Protocols: Modbus TCP, Modbus RTU, Profibus-DP, ABB proprietary industrial protocol
  • Data Storage: ≥1000 alarm & operation events, historical trend local storage supported
  • Mounting: Cabinet panel embedded installation
  • Display View Area: 115.2mm × 86.4mm
  • Net Weight: 0.78kg
  • Protection Class: Front IP65, Rear Terminal IP20
  • Supporting Equipment: AC800M controller, shielded communication cables, 24VDC redundant control power supply
  • Commissioning Tools: ABB Panel Builder software, network cable tester, insulation resistance tester, anti-static wristband


Supporting System

Supporting Hardware

ABB AC800M DCS controller, 800xA distributed control system, industrial redundant switch, DC operation power panel, field sensors and actuators.

Commissioning Software

ABB Panel Builder, used for HMI screen configuration, variable binding, alarm setting, communication parameter configuration, project download, multi-language editing and firmware upgrade.

Upper-level System

Plant DCS, SIS and SCADA platforms realize centralized remote monitoring by synchronizing local operation events and equipment fault information uploaded from the panel.

Typical Application Industries

Combined-cycle thermal power plants, hydropower stations, petrochemical refineries, natural gas pipeline stations, steel metallurgy production lines, waste incineration power plants and pulp & chemical process automation industries.


Product Features

  1. Industrial Reliable Physical Keypad Design: Dust-proof, oil-resistant and anti-misoperation, suitable for high-frequency on-site equipment operation in humid and dusty field areas, effectively avoiding touch screen failure risks.
  2. Flexible Multi-protocol Networking Compatibility: Dual Ethernet + RS485 communication interfaces seamlessly connect ABB and third-party automatic control systems, reducing equipment renovation and spare part inventory costs.
  3. IP65 Sealed Front Industrial Protection: Waterproof and dustproof aluminum alloy sealed structure prevents internal circuit corrosion and short circuit caused by on-site moisture and dust intrusion.
  4. Multi-language Configuration & Complete Process Function Library: Equipped with trend, alarm, report and PID control components, supporting multi-level operation authority management to prevent accidental safety misoperation.
  5. Wide-temperature Rugged Industrial Design: Stable operation within 0℃~60℃, compliant with IEC EMC standards, high MTBF value to support long-term unattended continuous operation.
  6. Plug-and-play Compatible Replacement: Standard cabinet opening size and communication protocol enable rapid spare replacement only by replicating original IP and project parameters without on-site wiring modification.



II. Technical Specifications


2.1 Electrical Parameters

  • Model: PP826A, Part No.: 3BSE042244R2 / 3BSE042244R3
  • Rated Power Supply: DC24V (18~30VDC), power consumption ≤12W
  • Display: 5.7-inch TFT LED, 640×480, 262K colors, 50000-hour backlight life
  • Communication Withstand Voltage: 1500VAC/1min for isolated ports
  • Built-in Protection: Reverse polarity, overvoltage, ESD, port short-circuit current limiting, surge absorption protection
  • Core Functions: Local process monitoring, manual equipment control, PID parameter online tuning, alarm management, historical trend query, multi-level authority control, local process data storage.


2.2 Mechanical Parameters

  • Mounting Mode: Standard cabinet panel embedded installation
  • Housing: Aluminum alloy front panel, flame-retardant plastic rear cover
  • Operation Type: Dust-proof membrane physical keypad array
  • Interfaces: RJ45, RS485, DC24V power terminals
  • Net Weight: 0.78kg


2.3 Environmental Specifications

  • Operating Temperature: 0℃ ~ +60℃
  • Storage Temperature: -20℃ ~ +70℃
  • Humidity: 5%~85%RH, non-condensing, no corrosive or conductive dust

III. Key Features


  1. Intuitive On-site Full-process Visual Monitoring: Real-time display of temperature, pressure, flow, valve and motor operating status via dynamic graphics, bar charts and trend curves for field inspection.
  2. Secure Authorized Local Manual Operation: Hardware keys realize equipment start-stop and parameter modification with multi-level permission lock to eliminate unauthorized misoperation risks.
  3. Local Alarm Event Storage & Traceability: Automatically record fault time, location and type when process interlock or equipment abnormality occurs; historical records can be queried offline for accident analysis.
  4. Dual Communication Redundancy Design: Ethernet for high-speed picture transmission, RS485 as backup link ensures basic local monitoring even if single communication fails.
  5. Multi-language On-site Parameter Debugging: Supports online PID loop parameter tuning and threshold modification without portable commissioning laptops.
  6. Standard Local Operation Supporting Unit for Panel 800 DCS System: Widely adopted in new automation project deployment, old control cabinet technical renovation and annual plant preventive maintenance.


IV. Working Principle


After DC24V power-on and self-check of display, keypad and communication circuits, the panel loads local HMI project and establishes communication handshake with AC800M controller via preset IP and protocol. It cyclically reads process data for screen refresh, uploads field operation commands to the controller through key triggering, and automatically caches alarm and operation events to local non-volatile memory. After fault elimination, alarm reset and screen switching can restore normal local monitoring function.


V. Application Scenarios


  1. Local operation station maintenance, spare replacement and process parameter calibration for thermal & hydropower plant DCS and excitation control systems.
  2. HMI technical upgrading for petrochemical and gas compressor stations to improve on-site operation reliability under harsh dusty & humid working conditions.
  3. Intelligent renovation of old local monitoring equipment for steel and waste heat power plants to realize data storage and permission safety management.
  4. Preventive spare reserve and on-site interlock calibration for continuous production lines in pulp and chemical industries.
  5. Supporting local operation equipment deployment for overseas new industrial automation projects to simplify field commissioning and daily maintenance work.
