ABB PP825 5.7-inch resistive touch industrial human-machine interface
ABB PP825 5.7-inch resistive touch industrial human-machine interface

ABB PP825 5.7-inch resistive touch industrial human-machine interface

ABB PP825 5.7-inch resistive touch industrial human-machine interface

Brand： ABB

Product ID： PP825

Condition： New / used

Terms of payment： Paypal、T/T 、Western Union

Category:

Description

I. Basic Information


Model: PP825A

Part No.: 3BSE042240R1 / 3BSE042240R3

Brand: ABB

Series: Panel 800 V5.1 Industrial Operator Panel Series

Product Type: 5.7-inch Resistive Touch Industrial HMI Operator PanelCompatible Systems: ABB AC800M, 800xA, Freelance DCS Distributed Control Systems, widely applied in power, petrochemical, metallurgy process control, generator excitation and turbine control systems.


Product Positioning

This panel is the core local human-machine interaction device for industrial process control systems. It realizes bidirectional high-speed data communication with ABB controllers via Ethernet and isolated RS485 bus, supporting on-site process parameter monitoring, equipment manual control, fault alarm query and historical trend analysis. Equipped with aluminum alloy sealed front panel and IP65 protection grade, the resistive touch screen can adapt to harsh industrial sites with dust, moisture and strong electromagnetic interference, widely used in local operation station spare replacement, old cabinet HMI renovation and on-site automatic production operation & maintenance projects.


Hardware Architecture

  1. 5.7-inch CSTN Color LCD Display Unit: Industrial LED backlight screen with 320×240 resolution, supporting dynamic process graphics, real-time trend charts and alarm pop-up windows, with 50000-hour long service life to meet 24/7 continuous on-site monitoring requirements.
  2. Resistive Touch Screen Operation Unit: 4-wire resistive touch design supports glove operation, wear-resistant, oil-proof and anti-scratch, ensuring stable and reliable frequent on-site operation in harsh industrial environments.
  3. Isolated Dual-channel Communication Processing Unit: Equipped with RJ45 Ethernet and isolated RS485 interfaces, compatible with mainstream industrial protocols to realize stable bidirectional data interaction between local panel and upper control system.
  4. Large-capacity Local Non-volatile Storage Unit: Built-in flash memory supports cyclic storage of more than 1000 alarm and operation records, realizing offline fault traceability without relying on upper monitoring software.
  5. Wide-range Power Supply & Multi-level EMC Protection Unit: Built-in reverse polarity, overvoltage, ESD and short-circuit protection; full conformal coated PCB adapts to high-temperature, dusty and strong electromagnetic interference industrial working conditions.
  6. Standard Embedded Cabinet Mount Structure: Die-cast aluminum alloy front panel with passive heat dissipation design, no fan required, reducing on-site failure points and adapting to dense cabinet layout.


Mounting Specifications

  • Operating Power Supply: DC24V (18~32VDC wide range), total power consumption ≤10W
  • Display: 5.7-inch CSTN color LCD, 320×240 resolution, 250cd/㎡ brightness, 500:1 contrast ratio
  • Touch Type: 4-wire resistive touch, response time ≤10ms, glove operation supported
  • Communication Interfaces: 1×RJ45 Ethernet, 1×isolated RS485
  • Supported Protocols: Modbus TCP, Modbus RTU, Profibus-DP, ABB proprietary industrial protocol
  • Data Storage: ≥1000 alarm & operation events, historical trend local storage supported
  • Mounting: Cabinet panel embedded installation
  • Net Weight: 0.4kg
  • Protection Class: Front IP65, Rear Terminal IP20
  • Supporting Equipment: AC800M controller, shielded communication cables, 24VDC redundant control power supply
  • Commissioning Tools: ABB Panel Builder software, network cable tester, insulation resistance tester, anti-static wristband


Supporting System

Supporting Hardware

ABB AC800M DCS controller, 800xA distributed control system, industrial redundant switch, DC operation power panel, field sensors and actuators.

Commissioning Software

ABB Panel Builder, used for HMI screen configuration, variable binding, alarm setting, communication parameter configuration, project download, multi-language editing and firmware upgrade.

Upper-level System

Plant DCS, SIS and SCADA platforms realize centralized remote monitoring by synchronizing local operation events and equipment fault information uploaded from the panel.

Typical Application Industries

Combined-cycle thermal power plants, hydropower stations, petrochemical refineries, natural gas pipeline stations, steel metallurgy production lines, waste incineration power plants and pulp & chemical process automation industries.


Product Features

  1. Industrial Reliable Resistive Touch Design: Supports glove operation, dust-proof, oil-resistant and anti-misoperation, effectively avoiding touch screen failure risks in humid and dusty field areas.
  2. Flexible Multi-protocol Dual-link Networking Compatibility: Main Ethernet link for high-speed picture transmission, RS485 as backup communication channel, seamlessly connecting ABB and third-party automatic control systems to reduce equipment renovation and spare part inventory costs.
  3. IP65 Sealed Front Industrial Protection: Waterproof and dustproof aluminum alloy sealed structure prevents internal circuit corrosion and short circuit caused by on-site moisture and dust intrusion.
  4. Multi-language Configuration & Complete Process Function Library: Equipped with trend, alarm, report and PID control components, supporting multi-level operation authority management to prevent accidental safety misoperation.
  5. Wide-temperature Rugged Industrial Design: Stable operation within -20℃~+55℃, compliant with IEC EMC standards, high MTBF value to support long-term unattended continuous operation.
  6. Plug-and-play Compatible Replacement: Standard cabinet opening size and communication protocol enable rapid spare replacement only by replicating original IP and project parameters without on-site wiring modification.



II. Technical Specifications


2.1 Electrical Parameters

  • Model: PP825A, Part No.: 3BSE042240R1 / 3BSE042240R3
  • Rated Power Supply: DC24V (18~32VDC), power consumption ≤10W
  • Display: 5.7-inch CSTN color LCD, 320×240 resolution, 50000-hour backlight lifespan
  • Touch Response Time: ≤10ms
  • Communication Withstand Voltage: 1500VAC/1min for isolated ports
  • Built-in Protection: Reverse polarity, overvoltage, ESD, port short-circuit current limiting, surge absorption protection
  • Core Functions: Local process monitoring, touch-type manual equipment control, PID parameter online tuning, alarm management, historical trend query, multi-level authority control, local process data storage.


2.2 Mechanical Parameters

  • Mounting Mode: Standard cabinet panel embedded installation
  • Housing: Die-cast aluminum alloy front panel, flame-retardant plastic rear cover
  • Operation Type: 4-wire resistive touch screen
  • Interfaces: RJ45, isolated RS485, DC24V power terminals
  • Net Weight: 0.4kg


2.3 Environmental Specifications

  • Operating Temperature: -20℃ ~ +55℃
  • Storage Temperature: -25℃ ~ +65℃
  • Humidity: 5%~95%RH, non-condensing, no corrosive or conductive dust

III. Key Features


  1. Intuitive On-site Full-process Visual Monitoring: Real-time display of temperature, pressure, flow, valve and motor operating status via dynamic graphics, bar charts and trend curves for field inspection.
  2. Secure Authorized Local Manual Touch Operation: Touch buttons realize equipment start-stop and parameter modification with multi-level permission lock to eliminate unauthorized misoperation risks.
  3. Local Alarm Event Storage & Off-line Fault Traceability: Automatically record fault time, location and type when process interlock or equipment abnormality occurs; historical records can be queried offline for accident analysis.
  4. Dual Communication Redundancy Design: The backup RS485 link ensures basic local monitoring even if the main Ethernet communication fails, improving system operation reliability.
  5. Multi-language On-site Parameter Debugging: Supports online PID loop parameter tuning and interlock threshold modification without portable commissioning laptops.
  6. Standard Local Touch Operation Supporting Unit for Panel 800 DCS System: Widely adopted in new automation project deployment, old control cabinet technical renovation and annual plant preventive maintenance.


IV. Working Principle


After DC24V power-on and self-check of display, touch and communication circuits, the panel loads local HMI project and establishes communication handshake with AC800M controller via preset IP and protocol. It cyclically reads process data for screen refresh, uploads field touch operation commands to the controller, and automatically caches alarm and operation events to local non-volatile memory. After fault elimination, alarm reset can restore normal local monitoring function.


V. Application Scenarios


  1. Local operation station maintenance, spare replacement and process parameter calibration for thermal & hydropower plant DCS and excitation control systems.
  2. HMI technical upgrading for petrochemical and gas compressor stations to improve on-site touch operation reliability under harsh dusty & humid working conditions.
  3. Intelligent renovation of old local monitoring equipment for steel and waste heat power plants to realize data storage and permission safety management.
  4. Preventive spare reserve and on-site interlock calibration for continuous production lines in pulp and chemical industries.
  5. Supporting local operation equipment deployment for overseas new industrial automation projects to simplify field commissioning and daily maintenance work.
