Description
ABB MG160MD2-42FF300-F1
1. Basic Information
ABB MG160MD2-42FF300-F1 is an IE3 premium-efficiency three-phase asynchronous industrial motor, co-developed by ABB and Grundfos, specially designed for vertical multi-stage centrifugal pumps. Adopting 2-pole high-speed design and 15kW rated power, it supports S1 continuous duty and variable frequency drive operation.
Built-in PTC 160℃ winding temperature sensor provides overheat protection. With IP55 protection and Class F insulation, the motor features low noise, low vibration and high stability, widely used in water treatment, petrochemical, HVAC and power plant fluid delivery systems for long-term uninterrupted operation.
2. Core Technical Specifications
2.1 Electrical & Power Parameters
- Model: MG160MD2-42FF300-F1
- Type: 2-Pole IE3 Premium Efficiency Three-phase Asynchronous Motor
- Rated Power: 15 kW
- Rated Frequency: 50 Hz
- Rated Voltage: 3×380-415V (Delta) / 660-690V (Star)
- Rated Speed: 2930～2950 rpm
- Rated Current: 26.0～28.0A (Δ) / 15.6～16.2A (Y)
- Max Working Current: 28.5～31.0A (Δ) / 17.2～17.8A (Y)
- Starting Current: 660%～780% In
- Power Factor: 0.87～0.89
- Protection Sensor: Built-in PTC 160℃ winding temperature probe
2.2 Structural & Protection Parameters
- Pole Number: 2 poles
- Efficiency Class: IE3 Premium Efficiency
- Protection Grade: IP55
- Insulation Class: Class F
- Frame Size: 160MD dedicated vertical pump frame
- Installation Type: Vertical flange mounting
- Bearing Feature: High-precision wear-resistant long-life bearing
2.3 Environmental & Operation Parameters
- Operating Temperature: -20℃～+40℃
- Storage Temperature: -40℃～+85℃
- Humidity Range: 5%～95%RH (Non-condensing)
- Duty Cycle: S1 continuous operation
- Drive Mode: Direct-on-line / VFD variable frequency drive
- Vibration Level: Low vibration industrial standard
3. Main Features
- IE3 Premium Energy Saving: Optimized electromagnetic and core structure reduces operation loss, achieving high energy efficiency for long-term continuous running.
- Excellent VFD Compatibility: Stable speed and torque output under variable frequency drive, no high-frequency vibration or overheating, suitable for variable working condition regulation.
- Built-in Overheat Protection: PTC temperature sensor monitors winding temperature in real time, supporting over-temperature alarm and interlock shutdown to avoid motor burnout.
- Dedicated Vertical Pump Structure: 160MD frame perfectly matches Grundfos vertical multi-stage pumps for plug-and-play replacement without mechanical modification.
- High Environmental Adaptability: IP55 protection and Class F insulation resist dust, splash water and high temperature, ensuring stable operation in harsh industrial environments.
- Low Noise & Vibration: Precision dynamic balance calibration and high-quality bearings ensure smooth and quiet high-speed operation.
4. Typical Applications
4.1 Vertical Multi-stage Pump Driving
Specially matched with Grundfos CR series vertical multi-stage pumps, serving as the core power unit for process pressurization and fluid transportation in industrial plants.
4.2 Utility Water System
Widely used in factory cooling water circulation, production water supply, fire pressurization and domestic water supply systems with 24-hour continuous operation demand.
4.3 Water Treatment Industry
Applied in sewage treatment, pure water preparation and reclaimed water reuse systems, adapting to variable flow and long-term stable operation requirements.
4.4 Old Equipment Renovation & Replacement
Replaces old low-efficiency motors to upgrade system energy efficiency, reducing operation and maintenance costs for technical transformation projects.
4.5 Variable Frequency Process System
Matches VFD constant pressure and variable load process conditions, realizing energy saving and stable fluid parameter control.
