I. Functions and Technical Advantages

1. Core Functions

• Precise Terminal Identification: Compatible with the terminal spacing of all I/O modules (universal for digital and analog, including compact modules) in the AC500 series PLC, it can be directly snapped above the terminals, clearly marking the core information of each terminal (such as DI, DO, AI, AO channel numbers, corresponding equipment names, signal purposes, etc.), realizing the visualization of terminal functions and facilitating quick identification and operation.
• Convenient Writing and Modification: The surface of the label strip is designed for writing, compatible with ABB special marking pens and conventional industrial erasable marking pens. The handwriting is clear and not easy to fall off, and it also supports repeated wiping and modification, which can flexibly adapt to the identification update needs after on-site wiring adjustment, with strong practicality and no need for frequent replacement of label strips.
• Firm Snap-on Positioning: Adopting an integrated compact snap-on design, it strictly matches the size specifications of AC500 I/O modules (including compact ones). After snap-on, it is firm and not easy to loosen or shift, does not block the terminal wiring holes, does not affect the terminal wiring operation, and occupies less space, adapting to the installation layout of compact control cabinets.
• Universal Adaptability: As a universal front-end label strip for the AC500 series PLC, it does not need to distinguish module models and sizes (both regular and compact are compatible), and can be compatible with all AC500 I/O modules. Batch use can maintain the unity and standardization of terminal identification of the entire control system, reducing operation and maintenance management costs.

2. Key Advantages

• Genuine Original Compatibility: Designed and manufactured by ABB, with the material code 3BDH001031R0001, it is 100% compatible with all I/O modules (including compact ones) of the AC500 series PLC, with precise dimensions and close fit. It eliminates hidden dangers such as loose snap-on, terminal blocking, and identification misalignment caused by size deviation of third-party label strips, ensuring the stable performance of the identification function.
• Industrial-grade Durability: The housing is made of high-quality flame-retardant engineering plastic, which has excellent mechanical strength, anti-aging performance and flame-retardant properties. It adapts to complex environments such as temperature fluctuations, dust, and vibration in industrial control cabinets, and is not easy to deform, embrittle, or yellow, and can operate stably for a long time, adapting to harsh industrial scenarios.
• Easy Installation and Replacement: It can be directly snapped or disassembled manually without any tools, the installation is fast and efficient, and it can be completed by a single person; when disassembling, it can be removed by gently prying, the operation is simple, which is convenient for later identification update, module maintenance or label strip replacement, greatly improving operation and maintenance efficiency.
• Clear Visual Identification and Compact Design: Adopting a pure white writable surface, it forms a distinct contrast with the terminals and housing of the AC500 I/O module. The written identification handwriting is clear and eye-catching, and even in the control cabinet with low light, the terminal function can be quickly identified; at the same time, it adopts a compact structure, small in size, saving cabinet installation space, and adapting to compact I/O modules and small control cabinets.

II. Technical Specifications

III. Application Areas

• Factory Automation: In the AC500 PLC control cabinets of production lines such as automotive manufacturing, electronic processing, food and beverage, and mechanical processing, especially suitable for compact control cabinets, it is used for terminal identification of various I/O modules (including compact ones), facilitating quick identification of signal channels during production line commissioning and daily maintenance, avoiding wiring errors, and improving production efficiency.
• Process Industry: In the AC500 distributed control systems of process industries such as petrochemical, metallurgy, water treatment, cement, and pharmaceuticals, it adapts to the operation and maintenance needs of complex industrial scenarios and compact control units, ensuring that the I/O terminal identification is clear and standardized, helping operation and maintenance personnel quickly troubleshoot faults and adjust parameters.
• Infrastructure: The supporting I/O modules (including compact ones) of AC500 PLC in rail transit, power substation auxiliary systems, building automation, energy management and other fields are used for terminal signal identification, ensuring that operation and maintenance personnel can quickly identify terminal functions and ensure stable system operation, adapting to the layout of miniaturized control equipment.
• System Retrofit and Expansion: When the AC500 PLC system is retrofitted or the I/O modules are expanded (including the addition of compact modules), it is used for the terminal identification of new modules, keeping the entire system identification standardized and unified, facilitating later unified operation and maintenance management, and adapting to the upgrade and replacement needs of label strips in old systems.

IV. Installation and Use Guide

1. Pre-Installation Preparation

• Model Verification: Confirm that TA924F (3BDH001031R0001) is compatible with the used AC500 I/O module model (including compact ones), check that the label strip is undamaged, deformed, or yellowed, and the snap-on structure is intact, which can be normally snapped and disassembled.
• Environment and Safety: Disconnect the power of the control cabinet and wait for the capacitors to discharge for ≥ 5 minutes; wear an anti-static wristband to avoid static damage to the I/O module; the installation environment must be dry, free of condensation and dust accumulation, and ensure that the surface of the I/O module terminals is clean and free of foreign objects.
• Tools and Materials: Prepare ABB special marking pens (or erasable industrial marking pens) and cleaning brushes; use a cleaning brush to clean the snap-on area above the I/O module terminals to ensure the snap-on surface is flat and clean, especially paying attention to the cleaning of the snap-on groove of compact modules.

2. Installation and Use Operation

• Clean the Snap-on Surface: Use a cleaning brush to clean the snap-on area above the AC500 I/O modules (including compact ones), remove dust and oil stains, ensuring that the label strip fits closely after snap-on and is not easy to fall off or shift, avoiding looseness caused by an unclean snap-on surface.
• Write Identification Content: According to the terminal function (such as DI1, DO2, AI3, AO1, corresponding equipment name, signal purpose, etc.), use a special marking pen to write clear identification content on the surface of the TA924F label strip. The handwriting is concise and clear, avoiding modification; if modification is needed, it can be wiped with a special cleaning tool and rewritten.
• Snap-on Installation: Align the label strip with the written identification with the snap-on groove above the I/O module terminals, press gently, and a "click" sound indicates that the snap-on is firm; ensure that the label strip corresponds to the terminals one by one, without deviation or blocking the terminal wiring holes, and does not affect subsequent wiring operations. Pay special attention to the terminal spacing of compact modules to avoid snap-on misalignment.
• Inspection and Confirmation: Push the label strip gently to confirm that it is snapped firmly without looseness; check that the identification content is consistent with the terminal function, and the handwriting is clear and distinguishable; if there is an identification error or snap-on deviation, adjust or replace the label strip in time to ensure accurate identification.

3. Maintenance and Replacement

• During daily maintenance, regularly check whether the label strip is loose, falling off, yellowed, damaged or the handwriting is blurred, and fasten, wipe or replace it in time to ensure clear and stable identification. Pay special attention to the installation status of the label strip in the compact control cabinet to avoid looseness due to compact space.
• When the I/O module terminal function is adjusted or the module is replaced (including compact modules), gently pry off the label strip, rewrite the identification or replace it with a new label strip, snap it in place and check the consistency between the identification and the terminal function to ensure accurate identification.
• Avoid using corrosive cleaning agents to wipe the label strip to prevent material aging and handwriting falling off; if there are stains on the surface of the label strip, wipe it gently with a dry cloth; do not force prying when disassembling to avoid damaging the label strip snap or I/O module (especially the interface of compact modules is relatively precise, so extra care is needed).

V. Common Problems and Solutions

• Label strip cannot be snapped in place: Check if the I/O module is AC500 series (including compact ones); check if the label strip snap is deformed or damaged; clean the dust and foreign objects in the module snap-on groove, align the snap-on groove and press gently, do not force it to avoid damaging the snap or module, especially pay attention to the snap-on force of compact modules.
• Label strip is loose or falls off after snap-on: Check if the snap-on groove is clean and flat; confirm that the label strip is not deformed, re-snap and press firmly; if the label strip snap is aging or damaged, replace it with a new one; for compact modules, confirm that the snap-on position is precise to avoid loose snap-on due to space constraints.
• Handwriting is blurred and easy to fall off: Check if the marking pen is an industrial special erasable marking pen; avoid wiping the surface of the label strip with hands; if the handwriting is blurred, it can be rewritten after wiping, or directly replace it with a new label strip; avoid writing in high temperature and humid environments to prevent handwriting falling off.
• Label strip is yellowed, aging or damaged: Check if the temperature in the control cabinet exceeds the specified range and optimize heat dissipation; if it is severely aging or damaged, replace it with a new label strip in time to avoid operational errors caused by unclear identification; for compact control cabinets, regularly clean the dust on the surface of the label strip to extend its service life.
